TATA SONLINK 125 Specifications
Engine and Transmission
| Engine Type | Air cooled 4 stroke |
| Displacement | 125 cc |
| Max Torque | 10.6 Nm @ 6000 rpm |
| No. of Cylinders | 1 |
| Cooling System | Air Cooled |
| Valve Per Cylinder | 2 |
| Starting | Kick and Self Start |
| Fuel Supply | Fuel Injection |
| Clutch | Wet Multiplate |
| Gear Box | 5 Speed |
| Bore | 52.4 mm |
| Stroke | 57.8 mm |
| Compression Ratio | 9.9:1 |
| Emission Type | bs6-2.0 |
Features
| Instrument Console | Digital |
| Bluetooth Connectivity | Bluetooth |
| Navigation | Yes |
| USB Charging Port | Yes |
| Speedometer | Digital |
| Tripmeter | Digital |
| Odometer | Digital |
| Additional Features Of Variant | Autosail, (Trail – 92 mm), Ride Smart Feature, Side Stand Engine Cut-off |
| Seat Type | Single |
| Body Graphics | Yes |
| Passenger Footrest | Yes |
Features and Safety
| I3s Technology | Yes |
| Speedometer | Digital |
| Odometer | Digital |
| Tripmeter | Digital |
| Fuel Gauge | Digital |
| Additional Features | Autosail, (Trail – 92 mm), Ride Smart Feature, Side Stand Engine Cut-off |
| Passenger Footrest | Yes |
| Display | Yes |
Chassis and Suspension
| Body Type | Commuter Bikes |
| Body Graphics | Yes |
Dimensions and Capacity
| Width | 743 mm |
| Length | 2051 mm |
| Height | 1074 mm |
| Fuel Capacity | 10 L |
| Saddle Height | 798 mm |
| Ground Clearance | 170 mm |
| Wheelbase | 1273 mm |
| Kerb Weight | 123 kg |
Electricals
| Headlight | LED |
| Tail Light | LED |
| Turn Signal Lamp | Bulb |
| DRLs | Yes |
| Low Fuel Indicator | Yes |
Tyres and Brakes
| Front Brake Diameter | 240 mm |
| Rear Brake Diameter | 130 mm |
Motor & Battery
| Peak Power | 10.84 PS @ 7500 rpm |
| Drive Type | Chain Drive |
| Battery Type | Lead Acid |
| Transmission | Manual |
Underpinnings
| Suspension Front | Dia. 30 Telescopic |
| Suspension Rear | 5 step Adjustable Hydraulic Shock Absorbers |
| Brakes Front | Disc |
| Brakes Rear | Drum |
| Tyre Size | Front :-80/100-18, Rear :-100/80-18 |
| Wheel Size | Front :-457.2 mm,Rear :-457.2 mm |
| Wheels Type | Alloy |
| Frame | Diamond |
| Tubeless Tyre | Tubeless |
App Features
| Navigation assist | Yes |
